Feature
1. Reliable pedal Control and double speed improve the efficiency of the tire assembly;
2. New double speed reverse switch(Patented)extend the lift time.
3. 4th Generation assist arm(Patented)increase the smooth of control and the strength of rectangular arm is higher;
4. NewLeverless luouhting head(Patented)is made by special heat treatment process that increase durability and accuracy of angle;
5. Ergonomic design on mounting low Profile flat and super hard tires;
6. Super locking system.The adjustable center system equipped with universal adaptor for reverse tires.
Technical Parms
Model
| BD15 | Standard Accessories |
Outside Clamping
| 13‘’-28‘’ | Inflation Gauge |
| Max. Wheel Width | 350mm | Lever |
Max. Wheel Diameter
| 1080mm | Lubrication Box |
| Working Air Pressure | 8-10bar | Automatic Mounting Head
|
Bead Breaker Force(at 8 Bar)
| 2500kgf | Universal Adapotor |
Turnable Speed
| 1Speed / 6RPM 2Speed / 12RPM | Tire Lifter |
| Max. Wheel Lift | 85kg | Optional Accessories |
| Voltage / Power | 220V/50Hz/1PH/1.1KW 380V/50Hz/3PH/0.75KW | Hand held Bead Blast Systpm |
| N./G. Weight | 350/385kg |
|
| Packing Size | 138*113*184cm |
|
